by Mahdokht Shaibani, Research Fellow, Mechanical & Aerospace Engineering, Monash University

Lithium-ion batteries have changed the world. Without the ability to store meaningful amounts of energy in a rechargeable, portable format we would have no smartphones or other personal electronic devices. The pioneers of the technology were awarded the 2019 Nobel Prize for chemistry.

But as society moves away from fossil fuels, we will need more radical new technologies for storing energy to support renewable electricity generation, electric vehicles and other needs.

One such technology could be lithium-sulfur batteries: they store considerably more energy than their lithium-ion cousins – in theory as much as six times the energy for a given weight. What’s more, they can be made from cheap materials that are readily available around the world.

Until now, lithium-sulfur batteries have been impractical. Their chemistry allows them to store so much energy that the battery physically breaks apart under the stress.

However, my colleagues and I have engineered a new design for these batteries which allows them to be charged and discharged hundreds of times without breaking down. We hope to have a commercial product ready in the next 2–4 years.

What’s so good about sulfur?

Lithium-ion batteries require minerals such as rare earths, nickel and cobalt to produce their positive electrodes. Supply of these metals is limited, prices are rising, and their mining often has great social and environmental costs.

Industry insiders have even predicted serious shortages of these key materials in the near future, possibly as early as 2022.

In contrast, sulfur is relatively common and cheap. Sulfur is the 16th most abundant element on Earth, and miners produce around 70 million tonnes of it each year. This makes it an ideal ingredient for batteries if we want them to be widely used.

What’s more, lithium-sulfur batteries rely on a different kind of chemical reaction which means their ability to store energy (known as “specific capacity”) is much greater than that of lithium-ion batteries.

The prototype lithium-sulfur battery shows the technology works, but a commercial product is still years away. Mahdokht Shaibani, Author provided

Great capacity brings great stress

A person faced with a demanding job may feel stress if the demands exceed their ability to cope, resulting in a drop in productivity or performance. In much the same way, a battery electrode asked to store a lot of energy may be subjected to increased stress.

In a lithium-sulfur battery, energy is stored when positively charged lithium ions are absorbed by an electrode made of sulfur particles in a carbon matrix held together with a polymer binder. The high storage capacity means that the electrode swells up to almost double its size when fully charged.

The cycle of swelling and shrinking as the battery charges and discharges leads to a progressive loss of cohesion of particles and permanent distortion of the carbon matrix and the polymer binder.

The carbon matrix is a vital component of the battery that delivers electrons to the insulating sulfur, and the polymer glues the sulfur and carbon together. When they are distorted, the paths for electrons to move across the electrode (effectively the electrical wiring) are destroyed and the battery’s performance decays very quickly.

Giving particles some space to breathe

A CT scan of one of the sulfur electrodes shows the open structure that allows particles to expand as they charge. Mahdokht Shaibani, Author provided

The conventional way of producing batteries creates a continuous dense network of binder across the bulk of the electrode, which doesn’t leave much free space for movement.

The conventional method works for lithium-ion batteries, but for sulfur we have had to develop a new technique.

To make sure our batteries would be easy and cheap to manufacture, we used the same material as a binder but processed it a little differently. The result is a web-like network of binder that holds particles together but also leaves plenty of space for material to expand.

These expansion-tolerant electrodes can efficiently accommodate cycling stresses, allowing the sulfur particles to live up to their full energy storage capacity.

When will we see working sulfur batteries?

My colleagues Mainak Majumder and Matthew Hill have long histories of translating lab-scale discoveries to practical industry applications, and our multidisciplinary team contains expertise from materials synthesis and functionalization, to design and prototyping, to device implementation in power grids and electric vehicles.

The other key ingredient in these batteries is of course lithium. Given that Australia is a leading global producer, we think it is a natural fit to make the batteries herea.

We hope to have a commercial product ready in the next 2–4 years. We are working with industry partners to scale up the breakthrough, and looking toward developing a manufacturing line for commercial-level production.

This article is republished from The Conversation under a Creative Commons license.

Rebound effects

Many believe that an eco-efficiency approach aligns business’ economic objectives with the environmental objectives of reducing the use of natural resources. However, it is not that simple. We need to distinguish between the natural resources used per unit produced – often highlighted by companies engaged in an eco-efficiency approach – and the natural resources consumed overall, which are linked to global demand for these resources. It is this last point that determines the environmental impact.

For example, let’s examine the case of a car that is more fuel efficient, travelling more miles per gallon of gasoline. Less fuel is required to make the same trip, which also means that the same trip has now become cheaper. This money savings can encourage us to drive more, and therefore to consume more petrol – this is known as the “rebound effect”.

We observe the same effect for LED bulbs, which cost less to use than incandescent bulbs. We can make fewer efforts to turn off these low-consumption lights than those with incandescent bulbs, which can paradoxically can increase energy use.

By reducing production costs, eco-efficiency can thus have a “cost effect”: As production costs decrease, the selling price also decreases and, consequently, demand and production can rise. We consume more, which runs counter to our environmental objectives. This argument seems valid in mass markets. When total resource use increases as a result of an eco-efficiency policy, it is said that there is a “rebound”, with an ultimately negative impact on the environment.

The case of luxury goods

But there is also what we call a “negative rebound”, when resource use decreases more than expected. This is the case for luxury goods or niche markets, when companies use the green credentials of their products as a sign of differentiation. The consumer is then ready to pay more for greener products – for example for electric or hybrid cars or recyclable batteries. Today, hybrid cars are more expensive to produce than conventional ones, the process being relatively new and cost of development needing to be amortized. But at the same time, price is also higher because consumers are attracted to hybrid cars.

If companies take advantage of this and increase their prices, this results in a decrease in the quantities demanded and therefore in the total resources consumed. In the end, the environmental benefit is greater than expected. Paradoxically, it is when companies raise their prices for more eco-efficient products that the environmental impact will be most favourable.

To be genuinely beneficial to the environment, eco-efficiency policies must therefore not encourage demand too much and manage both the efficiency of resource use and the total amount of resources consumed. Such an holistic eco-efficiency management carefully balances the impact on price and demand, ensuring that good intentions become good environmental deeds.

Stanko Dimitrov (Associate Professor at the University of Waterloo, Canada) and Frank Figge (Professor at Kedge Business School) contributed to this article.

This article is republished from The Conversation under a Creative Commons license.
